ABB 5SHX2645L0004 3BHL000389P0104 可控硅 库存现货

ABB 5SHX2645L0004 3BHL000389P0104 是一款可控硅模块，由ABB（机器人）生产。可控硅设备通常用于电力电子应用，如电机控制、电力调整和温度控制。以下是关于这款可控硅模块的详细介绍：

1. 输入和输出端口：该模块通常具有输入和输出端口，用于连接到电路，并接收控制信号以调整电流和电压。
2. 控制功能：它可以用于控制和调整电路中的电流和电压，以适应不同的负载和应用需求。当条件施加到栅极的瞬时正脉冲时，它将NPN晶体管和PNP晶体管偏置为导通，使有效的hFE瞬间变得大于1，从而使特别耦合的晶体管饱和。这有助于实现电力调整和电子控制。
3. 应用领域：该模块广泛应用于多个行业，包括PCB行业（如PCB钻孔机、PCB插件机等）、半导体封装行业（如固晶机、超声波焊线机、IC烧录机等）、电子加工行业（如绕线机、点胶机、插件机等）、钣金加工行业（如铆钉机、数控冲床等）以及检测行业。
4. 技术指标：电机轴数为8，支持在PC机中同时工作的卡数为16。脉冲量输出为差分输出（也可单端输出），控制周期为1ms（不可调）。控制电机的脉冲信号频率范围为0Hz～2MHz，频率精度为0.0625 Hz。脉冲信号输出最大电流为20mA（吸入）。支持的插补坐标系个数为2，直线插补精度为±1 pulse，圆弧插补精度为±1.5 pulse。编码器信号输入个数为4，编码器输入信号频率为4倍频率增量式，最高频率为16MHz（4倍频后为16MHz）。

ABB 5SHX2645L0004 3BHL000389P0104 is a thyristor module produced by ABB (Robotics). Silicon controlled devices are commonly used in power electronics applications, such as motor control, power regulation, and temperature control. The following is a detailed introduction about this thyristor module:

Input and output ports: This module typically has input and output ports for connecting to circuits and receiving control signals to adjust current and voltage.

Control function: It can be used to control and adjust the current and voltage in the circuit to adapt to different loads and application requirements. When the condition is applied to the instantaneous positive pulse of the gate, it biases the NPN transistor and PNP transistor to conduct, making the effective hFE instantly greater than 1, thereby saturating the specially coupled transistor. This helps to achieve power adjustment and electronic control.

Application areas: This module is widely used in multiple industries, including the PCB industry (such as PCB drilling machines, PCB plug-in machines, etc.), semiconductor packaging industry (such as solid crystal machines, ultrasonic soldering machines, IC burning machines, etc.), electronic processing industry (such as wire winding machines, dispensing machines, plug-in machines, etc.), sheet metal processing industry (such as riveting machines, CNC punching machines, etc.), and testing industry.

Technical indicators: The number of motor shafts is 8, and the number of cards supporting simultaneous operation in PC is 16. The pulse output is differential output (or single ended output), with a control period of 1ms (not adjustable). The frequency range of the pulse signal for controlling the motor is 0Hz to 2MHz, with a frequency accuracy of 0.0625 Hz. The maximum current output of the pulse signal is 20mA (suction). The number of supported interpolation coordinate systems is 2, with a linear interpolation accuracy of ± 1 pulse and a circular interpolation accuracy of ± 1.5 pulse. The number of input signals for the encoder is 4, and the frequency of the encoder input signal is a 4-fold frequency increment, with a maximum frequency of 16MHz (16MHz after 4-fold frequency).
